PCB Design

ABP Electronics Limited is a one-stop EMS supplier integrating PCB design, PCB manufacturing, Component sourcing and PCB assembly.

R&D Capability

ABP Electronics has professional engineering designers and experienced development engineers. With many years of R&D experience in the fields of circuit design and electronic product development, we can efficiently complete design projects according to customer’s needs.

After 17 years of growth, ABP Electronics has not only attracted many outstanding R&D engineers in the industry, but also constantly updated production equipment and developed new production processes. Meanwhile, with three bases, Shenzhen Xili Headquarters, Shenzhen Songgang Factory, and Dongguan Houjie Factory, ABP is endowed with capabilities to support customers from PCB design, PCB manufacturing to PCB assembly.

Maximum signal processing rate: 56Gbps Differential signalDesigning for Board Level EMC
Maximum Layer: 32LCE、FCC Certification
Minimum BGA pitch: 0.4mmRF Design and analysis
Minimum Trace Width/Space: 2.5/2.5milHDI Design
Minimum Hole Dimension: 3mil
Maximum Number of Connection: 50000DFX Design: DFM、DFA、DFT、DFC
Maximum pin quantity: 60000FPC Design:20L Rigid-flex PCB
Maximum number of BGA: 45Signal integrity design
Maximum number of BGA Chip pins: 4094Power integrity design

Design field

Wireless ProductsGPS, Base Station, Network Optimization, Wi-Fi Module, Microwave System
Multimedia ProductsSet-top box、VOIP、Meeting TV,Video capture equipment, etc.
PC and relatedMB、NB、Server motherboards and various industrial control boards, etc.
Consumer ProductsHD TV, Tablet Computer, Digital Camera, Camcorder, Mobile Phone, etc.
Security ProductsVideo surveillance equipment, walkie-talkies, etc.
Military Industry and AerospaceBlack box, radar, remote sensing, telemetry, etc.
Communication ProductsRouters, switches, wireless terminals, optical networks, gateways, etc.
Medical EquipmentUltrasound, CT, MRI, Monitor, etc.

Success Case



pcb design case
